Product Description
QUEST QTVCS REMOTE CONTROL
แผงควบคุม QTVCS Remote Source Select/Volume Control Will operate up to 50m over standard Cat 5 Has facility for a 24v power input for distances greater that 50m
The QTVCS is a remote control panel designed to work together with Q Matrix 88. The QTVCS is suitable for use as a remote source selector and a volume controller for signals fed into the zone via the Q Matrix 88.
The remote control panel is designed with an LED to provide direct display of the selected sources, with up and down buttons to be used for changing source material from the Q Matrix 88.
A ten level volume control is provided for control over the selected source. Communication between the panel and the Matrix is achieved via industry standard CAT5 cable which also is used to supply power from the Matrix to this panel when the distance is < 50 meters. A total of 8 remote control panels can be used with each Matrix unit.
Features:
- Will operate up to 50m over standard Cat 5
- Has facility for a 24v power input for distances greater that 50m
- Inbuilt relay so BGM is muted in emergency situations
- Steel wall mount box available for sturdy installation
- Colour white
