เครื่องผสมสัญญานเสียง TOA M-243 H Stereo Mixer

Name: เครื่องผสมสัญญานเสียง TOA M-243 H Stereo Mixer
SKU: 4055
Price: 23500.00 THB
Availability: InStock

เครื่องผสมสัญญานเสียง TOA M-243 H Rack-mountable stereo mixer 2-monaural inputs, 4-stereo inputs, 1-stereo output and 2-monaural outputs

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…..

฿23,500.00

Product Description

เครื่องผสมสัญญานเสียง TOA M-243 H Rack-mountable stereo mixer 2-monaural inputs, 4-stereo inputs, 1-stereo output and 2-monaural outputs

The M-243 is a 19″ rack-mountable stereo mixer that comes with two monaural inputs, four stereo inputs, one stereo output and two monaural outputs.

2 mono and 4 stereo inputs, 1 stereo and 2 mono outputs plus 1 stereo and 2 mono sub-inputs to the output mix buses
Each input can be assigned to any combination ofthe three outputs
Switchable high pass filter on each monaural input to filter out unwanted low frequencies, especially for speech use

Power source	220 – 240 V AC, 50 / 60 Hz
Frequency response	20 Hz – 20 kHz (+1 /-2 dB)
Distortion	< 0.01 % (at 1 kHz, rated input/output)
Power consumption	10 W
S/N ratio	Noise Level (IHF-A): When all volume controls are in minimum position: Stereo Output (L,R): -105 dBu or less Monaural Output (1,2): -98 dBu or lessWhen the stereo, monaural (1,2) are in maximum position: Stereo Output (L,R): -94 dBu or less Monaural Output (1,2): -95 dBu or less
Inputs	Monaural Input: Line: -10 dBu, 10 kΩ, unbalanced, ø 6.3 mm phone jack (2P) Mic: -60 dBu, 1 kΩ, balanced, XLR3-pin connector Mic (Pad): -40 dBu, 1 kΩ, balanced, XLR3-pin connector Stereo Input (L,R): -10 dBu, 10 kΩ, unbalanced, RCA jack Auxiliary Stereo Input: +4 dBu, 50 kΩ, unbalanced, ø 6.3 mm phone jack (2P)
Outputs	Stereo Output +4 dBu, 1 kΩ, unbalanced, ø 6.3 mm phone jack (2P) Monaural Output (1,2) +4 dBu, 1 kΩ, unbalanced, ø 6.3 mm phone jack (2P) REC Output (L,R) -10 dBu, 1 kΩ, unbalanced, RCA jack
Finish	Aluminium, black
Dimensions	483 x 46 x 301.8 mm (W x H x D)
Weight	3.8 kg
Accessory (included)	Rack mounting screw x 4, Rubber foot x 4, Knob (blue, small) x 2, Knob (red, small) x 2, Knob (blue, large) x 1, Knob (red, large) x 1, Power cord (2 m) x1
