Product Description
Amphenol KS3P 3.5 mm 3-Pole Stereo Phone Plug Connector
หัวแจ็คโฟนแบบ 3.5mm Amphenol KS3P 3.5 mm 3-Pole Stereo Phone Plug Connector, Diecast Shell, Precision-Machined Contacts, Quick Assembly 3 Piece Design, For Cables 2.5 to 5mm Diameter, เหมาะสำหรับทำสายสัญญานทั้ง งาน Audio
The nickel Amphenol KS3P 3.5mm 3-Pole Stereo Phone Plug Connector by Amphenol Audio Products is for soldering to studio-quality cables and is engineered for critical recording and broadcast applications.
It features a diecast shell with precision-machined contacts. The connector is offered with a flexible grommet to help protect the cable. This K series connector is RoHS compliant.
Features:
- Diecast Shell
- For Cables 2.5 to 5mm Diameter
- Precision-Machined Contacts
- Quick Assembly 3 Piece Design
Specifications
Materials
| Shell Material |
Diecast Zinc Alloy EZDA No.3 |
| Finish |
Connector Shell Finish: Satin-nickel |
| Insulator |
PA66 |
| Bushing |
Santoprene |
| Contacts |
Brass |
| Plating |
Nickel |
General
| Contacts |
3-pole |
| Termination |
Solder |
| Wire Gauge |
AWG 18 – 1mm² |
| Flammability Rating |
Rating of Insulated Plastics: UL94V-0 |
| Solderability |
Complies with IEC 68-2-20 |
| Environmental |
Complies with EU RoHS 2 Directive 2011/65/EU |
Electrical Characteristics
| Maximum Current Capacity |
>0.5 mA (depends on mating connector and cable) |
| Contact Resistance |
≤ 20 mOhm (depends on mating connector and cable), typical |
| Insulation Resistance |
Initial: > 200 MOhm
After damp heat test: > 100 MOhm |
| Voltage |
Test voltage AC RMS: 250 VAC |
Environment
| Protection Class |
IP40 |
| Operating Temperature |
-4 to +149°F / -20 to 65°C |
Mechanical Characteristics
| Insertion / Withdrawal Force |
< 20 N / > 3 N (depends on mating connector) |
| Mechanical Operation |
1000 mating cycles |
| Cable O.D. |
0.118 to 0.196″ / 3 to 5 mm |
| Weight |
0.3 oz / 8 g |
