Product Description
Atlas FAP33T Ceiling Speaker 3″ 16 watt
ลำโพงห้องประชุมแบบติดฝ้าเพดาน Atlas FAP33T ดอกลำโพงขนาด 3 นิ้ว, 3″ Full Range In-Ceiling Loudspeaker With 16-Watt 70v/100v Transformer, Power Tap 2, 4, 8, 16 Watts & 6Ω , Frequency Response 85Hz – 12kHz
The white FAP33T-W Strategy III Series 3″ 70.7/100V-16W Ceiling Loudspeaker from Atlas is a factory assembled loudspeaker that is optimally tuned, ported in an enclosure, and built with a 16W, 70.7/100 V transformer. It can be used in several environments in applications for retail stores, restaurants, recreational facilities, hotels, casinos, and more.
A convenient front mounted selector switch allows tap selection without the need to remove the loudspeaker from the ceiling. This switch also has a transformer bypass setting for 6 Ohm direct coupled operation. In addition, easy installation in drop tile or sheetrock ceilings via the C-Ring/V-Rail tile bridge that is included.
There is a Safety First Mounting System that protects from over-torquing the mounting doglegs during installation and potentially cracking or breaking the mounting system. The result is no install tools required, no over-torqued doglegs, and no rusted screws, and quick installation.
Features:
- SFMS – Safety First Mounting System Patented Design Allows for Quick, Easy Installation
- 4 Pole Detachable “Phoenix” Style Connector Allows Easy Pre-Wiring and is Convenient for Daisy Chaining of Additional Speakers
- Enhanced Quality 70.7V/100V Internal Transformers Minimize Insertion Loss
- Increased Dispersion with Improved Waveguide
- Front Mounted Tap Selector Switch for Easy System Tuning Adjustments Includes Transformer Bypass Setting for Direct Coupled Operation
- “Press Fit” Grilles Blend Better into Contemporary Architecture
- Unique “Trap Door” Input Section Allows for Through Conduit Runs with Rigid or Flex Conduit
