จอมัลติมีเดียกระดานอัจฉริยะ 75″ Newline TT-7522Z Interactive Display

จอแสดงผล Interactive หน้าจอสัมผัสอัจฉริยะพร้อมกล้อง,ไมโครโฟนแบบ Array และ OPS Computer, Newline Z-Series TT-7522Z ขนาดจอ 75 นิ้ว, 4K UHD (3840 x 2160) Native Resolution, 400 cd/m² Brightness, Built-In Wi-Fi 6

ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม…..

฿229,000.00

Quantity:

สอบถามและสั่งซื้อสินค้า

Category: Tag:
Share This:

Product Description

Newline Z-Series TT-7522Z 75″ 4K PCAP Touchscreen Interactive Display with OPS Computer and 4K Camera

จอแสดงผล Interactive หน้าจอสัมผัสอัจฉริยะพร้อมกล้อง,ไมโครโฟนแบบ Array และ OPS Computer, Newline Z-Series TT-7522Z ขนาดจอ 75 นิ้ว, 4K UHD (3840 x 2160) Native Resolution, 400 cd/m² Brightness, Built-In Wi-Fi 6

The Newline Z Series TT-7522Z-UC 75″ 4K PCAP Touchscreen Interactive Display with OPS Computer and 4K Camera brings an immersive and effective collaboration experience to classrooms and workspaces.

Utilizing a 4K UHD resolution and 400 cd/m² of brightness, this display offers ample detail for engaging content. Built-in Wi-Fi 6 connectivity enables wireless communication, while a USB Type-C input supports data, video, audio, and up to 65W of power delivery via a single cable.

Plus, an integrated OPS computer provides onboard processing power, while the included 4K camera allows for easy video conferencing.

Features:

  • Active Screen Size 75″
  • Display 4K/LED/3840 x 2160 pixels/5000:1
  • Response Time 8ms
  • Viewing Angle 178°
  • Display Life Time 50,000 Hours
  • LCD Brightness 400 cd/m2
  • Touch type PCAP/40 Point Anti-Glare/Anti-Fingerprint/Tempered Glass/Anti-Bacterial Glass/7H
  • Writing Tools Passive Pen/ Finger/Palm
  • Top -Front Speaker 20W X2 + 15W Subwoofer
  • Mic Upper Front 8-Mic Array
  • Camera Module 4K@30Hz/UHD/View Angle 120°/ Tile Range 15°
  • Connectivity Wi-Fi Module/HDMI IN 2.0/HDMI OUT 2.0/USB 3.0 Type C/USB-A3.0/USB Type-B (Touch)/Display
  • Port 1.2/Mic In/VGA/LAN in/RS232/RJ45/OPS Slot/SDM-S Slot/ S/PDIF/Audio Line Out
  • Wifi Module WIFI 6 + BT 5.2
  • Operating System Android 11.0 4GB RAM/32GB ROM/64 GB External Memory
  • Newline Cast & Broadcast/Launcher Control/Teach Infinity II/Display MGT+
Category: Tag:

Specifications

Display
Active Screen Size 75″
Backlight DLED
Display Area (Mm) 1650 x 928 mm
Display Ratio 16:9
Resolution 3840 X 2160 (4K)
Colors 1.07Billion ( 10 Bit Color )
Brightness 450 Cd/M²
Contrast Ratio 15000:1
Response Time 4ms
Viewing Angle H = 178, V = 178 Typ.
Display Life Time (MTBF) ≥ 50000  Hours
Electrical
Working Voltage Ac100-240v Max 4.0a
Power Consumption (Eco Mode) <240W
Power Consumption (Standby Mode) <0.5W
TOUCH
Touch Surface Material Metal Mesh
Glass Surface Technology Antiglare+Anti-Fingerprint Tempered Glass
Touch Surface Antimicrobial Tempered Glass
Touch Sensor Optical Bonding
Transparency Projective Capacitive (PCAP)
Haze 88%±3
Touch Surface Hardness 2%~5%
Hid Support 7h
Touch Points Yes
Touch Screen Writing Tools 20 Point/ Optional Windows 40point
Positioning Accuracy Passive Pen/ Fingers
Touch Surface Material ±1mm
Speaker
Speaker Position Top-Front
Speaker Rated Impedance 180hz-20khz When SPL Is -10db
Speaker Freq.Response 6ω
Output S.P.L. 0db~ -10db
Speaker Max.Power Output 20wx2 + 15w Subwoofer
Microphone
Mic Position 8-Mic Array – Upper Front
Distance 8m
Camera Module
Camera Resolution 4k@ 30 Hz /UHD
Field Of View 120° FOV Lenses
Camera Tile Range 15°
Transportation / Storage
Storage Temperature/Humidity -20~60°C & 0~90%Rh (Non-Condensing)
Working Temperature/Humidity 0~40°C & 20~80%Rh (Non-Condensing)
Installation Method (Optional) Wall-Mounted / Mobile Stand
Outline Dimension
(Without Wall Mount Bracket Thickness)		 1719.3 x 1043.7 x 85 mm
Packing Dimension 1859 x 227 x 1160 mm
Net Weight 50 Kg
Gross Weight 64 Kg
Smart System
Soc Chipset Amlogic 311D2
Ram 8gb
Flash Memory 64gb
Android Version Android 11




Multimedia File Formats Support

 Image: Jpeg, Bmp, PNG

Video: Mpeg1, Mpeg2, Mpeg4, Sorenson H.263, H.263, H.264, HEVC/H.265, MVC, AVS, AVS+, WMV3, VC1, MOTION JPEG,VP8, VP9, RV30/RV40

Audio:Mpeg1/2 @Layer1;@Layer2;@Layer3, Eac3, Acc-Lc, He-AAC, VORBIS, LPCM, IMA-ADPCM, MS-ADPCM, G711 A/MU-LAW, LBR(COOK), FLAC”
Side I/O
USB Type-C (Pd 65w/100w Optional) 1
HDMI In 2.0 1
USB Type-B (Touch) 1
USB 3.0 Type-A 1
Microphone In 1
Rear I/O
HDMI In 2.0 2
Displayport 1.2 1
USB Type-B (Touch) 3
USB 3.0 Type-C (No PD) 1
USB 3.0 Type-A 2
USB 3.0 Type-A To Android 1
HDMI Out 2.0 1
Rs232 1
Rj45 (Gigabit) IN*1 & OUT*1
Ops 1
SPDIF 1
Audio Line Out 1
WIFI Module 1
Proximity Sensor 1
SDM-S Slot Yes

Downloads

ดาวน์โหลด Data Sheet Newline TT-7522Z

ดาวน์โหลด Brochure Newline Z- Series
